Cu-Ni Drum Screens
The Cu-Ni Drum Screen is the copper-nickel water intake screen, the best choice for filtration in seawater systems. Provide specialized service for the drum screen.
-
Cu-Ni 70/30 material offers excellent corrosion resistance, especially when operating in seawater.
-
The wedge wire structure prevents clogging of the filter and withstands heavy pressure loads.
MAKİNSAN specializes in custom-manufactured Cu-Ni intake drum screens (Copper-Nickel Water Intake Screens). These screens deliver superior performance in seawater systems.
The intake drum screen ensures optimal water intake while minimizing impacts on marine life and reducing maintenance requirements. It is designed with a focus on durability, efficiency, and environmental protection.
Details of the Copper-Nickel Suction Drum Screen
-
The wedge wire screen structure prevents filter clogging.
-
The wedge wire design withstands heavy pressure loads.
-
The precise positioning of flange holes ensures easy installation.
-
Cu-Ni 70/30 material provides excellent corrosion resistance, particularly in seawater.
Cu-Ni Emme Tambur Elekleri için Teknik Parametreler
Malzeme Cu-Ni 70/30
| Bileşen | Malzeme |
| Profil teli | Cu-Ni 70/30 |
| Destek çubuğu | Cu-Ni 70/30 |
| Kafa flanşı | Cu-Ni 70/30 |
| Yan flanş | Cu-Ni 70/30 |
| Yan tüp | Cu-Ni 70/30 |
| İç tüp | Cu-Ni 70/30 |
| Bu filtrenin tüm parçalarının malzemesi Cu-Ni 70/30'dur. | |
Item Content
| C | Mn | Ni | Fe | S | P | Cu | AI | Si | Ti |
| ≤1% | ≤30% | the rest | ≤0.3% |
Mekanik Özellik
| Süneklik % (>1,0) | Erime noktası | Uzatma gücü | Elektriksel direnç Ω | Maksimum SICAKLIK °C |
| ≥25 | 1180 | ≥400 | 0.35±0.03 | 400 |
Flow Rate and Operating Pressure
| Length (mm) | Diameter (mm) | Slot (mm) | Profile Wire Width (mm) | Open Area | Cylindrical Screen Flow Rate (m³/h) | Lower Flow Rate (m³/h) | Total Flow Rate (m³/h) | Operating Pressure |
|---|---|---|---|---|---|---|---|---|
| 800 | 500 | 2 | 2 | 50% | 753.6 | 113.8 | 871.4 | Max 10 bar |
Key Features of the Copper-Nickel Suction Drum Screen
-
Superior Corrosion Resistance
The suction drum screen is made of high-quality copper-nickel alloy (Cu-Ni 70/30), offering outstanding resistance to seawater corrosion, biological fouling, and erosion. -
High-Efficiency Filtration
The design of the screen maximizes water flow while preventing clogging and reducing maintenance frequency. -
Environmental Protection
Copper-nickel material naturally inhibits marine growth, reduces the need for chemical treatments, and supports environmentally friendly operation. -
Easy Installation and Maintenance
The modular design allows easy access and replacement of components, reducing downtime and maintenance costs.
Applications of Copper-Nickel Suction Drum Screens
The Copper-Nickel Intake Drum Screen is ideal for various seawater systems, including:
-
Desalination Plants
-
Power Plants
-
Offshore Oil and Gas Platforms
-
Marine Aquariums
-
Coastal Industrial Facilities
